B-Line
B 18 SFi M
Available in:Africa, Australasia, Caribbean, Central America, East Asia, EU, Europe, Middle East, North America, Oceania, South America, South Asia, Southeast Asia
Technical details
| Modellname | B 18 SFi M |
|---|---|
| Typ | Stapelrahmen für M-F3A PRO und B 18 Subwoofer |
| MECHANISCHE DATEN | |
| Material | 9 und 12 mm Schichtholz |
| Oberfläche | Schwarze oder weiße Polyurea-Beschichtung |
| Produktabmessungen [H × B × T] (inkl. Befestigung) | 97.5 × 512 × 793 mm |
| Nettogewicht | 13,8 kg |
| Verpackungsabmessungen [H × B × T] | 163 × 590 × 875 mm |
| Gesamtgewicht | 16,1 kg |
| Ausstattung | Zwei seitliche, in das Gehäuse eingelassene Griffe Vier Gummifüße und obere Schlitze für Stapelung Front SE Audiotechnik® Backlight-Panel |
| Rigging | Zweipunkt-SE Audiotechnik® Stapelsystem Dreipunkt-Aufhängesystem mit 6 mm SE Audiotechnik® Sicherungsbolzen |
| Neigungswinkel | 0º, -2,5º, -5º |
| ELEKTRISCHE DATEN | |
| Anschlüsse | Stromeingang: powerCON® 20 A Strom-Link-Ausgang: powerCON® 20 A |
| Belegung | Pin N: Neutral Pin L: Leiter Pin E: Schutzleiter |
| Netzspannungsbereich | 100 – 240 VAC 50/60 Hz, 20 A |
| Stromverbrauch | 30 W |
Related products and accessories
Packaging:
Cardboard outer packaging: 90.82% (1880 g) | Foam inner padding: 6.04% (125 g) | Plastic protective sleeve: 3.14% (65 g)
The following overview contains information on the regulated substances used in the product and on compliance with the applicable limit values.
"Lead (Pb): Used in printed circuit boards (printed circuit board | electronic components on the PCB | internal connecting wires | copper traces) (permitted exemption).
"
"Lead (Pb): Used in connectors (electrical connectors) (permitted exemption). "
Mercury (Hg): The content is not detectable or is below the applicable regulatory limits.
Cadmium (Cd): The content is not detectable or is below the applicable regulatory limits.
Hexavalent Chromium (Cr(VI)): The content is not detectable or is below the applicable regulatory limits.
Polybrominated Biphenyls (PBB): The content is not detectable or is below the applicable regulatory limits.
Polybrominated Diphenyl Ethers (PBDE): The content is not detectable or is below the applicable regulatory limits.
"Lead (Pb): Used in connectors (electrical connectors) (permitted exemption). "
Mercury (Hg): The content is not detectable or is below the applicable regulatory limits.
Cadmium (Cd): The content is not detectable or is below the applicable regulatory limits.
Hexavalent Chromium (Cr(VI)): The content is not detectable or is below the applicable regulatory limits.
Polybrominated Biphenyls (PBB): The content is not detectable or is below the applicable regulatory limits.
Polybrominated Diphenyl Ethers (PBDE): The content is not detectable or is below the applicable regulatory limits.
Environmental Protection Use Period: 15 year(s)
